10Mb (10 Base-T1S)
.svg)
100 Mb (100 Base-T1S)
.svg)
1 Gb (1000 Base-T1S)
2.5 Gb
CAN
Show Ability to Route Signals from 1G ETH to 100M, 10M ETH, and CAN
➤ Turn On / Off Each of the 5 EN Motors from CIP Display
Show Redundancy
➤ CIP GUI Shows Network Performance as Demo 1 is performed
➤ Case 1 to Case 2 1G ETH Cable is Manually Disconnected
➤ Continue Turning EN1, EN2 and EN3 On/Off with No Observed Delay
Show Bandwidth and
Traffic Shaping
➤ Turn EN3 and EN4 On/Off Simultaneously (good sync)
➤ As Side-Traffic Inserted, Delays Become Observable (poor sync)
➤ CIP GUI Used to Prioritize Bandwidth / Traffic Shaping
➤ Even with Side-Traffic, Simultaneous (good sync)
Multi-platform
Support
➤ Application to Reverse Motor Direction of Motor Resident in CIP
➤ Turn On Reverse Function in EN3 or EN4
➤ Observe EN3 or EN4 Motor Spinning in Opposite Direction
➤ Observe Network Traffic as ZC1 or ZC2 Subscribes to Reverse Motor App
