Enhanced Automotive and Safety Systems
TSN (Time Sensitive Networking) adds guaranteed latencies for automotive control functions & the ability to build redundant network paths for safety-critical communications. Excelfore AVB/TSN is AVNU certified, so you also get interoperability with other certified AVB/TSN devices.
Scalable Network Bandwidth and Dynamic Switching
Ethernet enables cost-effective in-vehicle bandwidth scaling from 10MB multi-drop to 10GB and beyond. It also brings dynamic network switching, network security and the ability to reach devices from the Cloud.
IP Addressing and Accessibility for CAN Buses
SOME/IP, DoIP, RTP, RTCP and UDS protocols from Excelfore bring your legacy systems forward into the age of the Software Defined Vehicle, integrating seamlessly into an Ethernet backbone to provide full cloud accessibility to your CAN based devices.
Precise Synchronization, Redundant Grandmaster & IEEE1588 Support
TSN networks provide a grand master clock to enable network traffic and connected devices to precisely synchronize across the network
➤ Generalized precision time protocol (gPTP) and redundant grandmaster: IEEE 802.1AS-2020
➤ Multi Clock Domain Support: IEEE1588
Guaranteed Latency
Properly constructed TSN networks guarantee the latency from source to destination across the network, ensuring precision control, decision algorithms and actuations meet specified timing requirements.
Managed Network Redundancy & Advanced Traffic Shaping
Key TSN protocols build redundancy into networks in safety-critical domains:
➤ Redundant data paths: IEEE 802.1Qcb
➤ Redundant grand master clocks: IEEE 802.1A 2020 / 802.1ASrev
➤ High-precision grand master clock: IEEE 802.1AS-2020
➤ Stream reservation protocol: IEEE802.1Qcc
➤ Time aware shaper: IEEE 802.1Qbv
➤ Asynchronous traffic shaping: IEEE 802.1Qrc
➤ Traffic pre-emption: IEEE 802.1Qbu
Audio Video Bridging Standards Supported
AV-over-IP.
Number of 10/100/1000 Mbps Ports: 10
Certifications: AVNU/AVB
Audio Video Bridging Standards Supported
AV-over-IP.
Number of 10/100/1000 Mbps Ports: 10
Certifications: AVNU/AVB
Appropriate for Automotive Control
Guarantees Delivery Time in Configured Range
IN ALL CASES: When Configured for 1msec, Critical Data Reaches Destination within 1msec
TAS Effect is Significant
Propagation Delay Consistently <100 µsec
Enhanced Automotive and Safety Systems
TSN (Time Sensitive Networking) adds guaranteed latencies for automotive control functions & the ability to build redundant network paths for safety-critical communications. Excelfore AVB/TSN is AVNU certified, so you also get interoperability with other certified AVB/TSN devices.
Scalable Network Bandwidth and Dynamic Switching
Ethernet enables cost-effective in-vehicle bandwidth scaling from 10MB multi-drop to 10GB and beyond. It also brings dynamic network switching, network security and the ability to reach devices from the Cloud.
IP Addressing and Accessibility for CAN Buses
SOME/IP, DoIP, RTP, RTCP and UDS protocols from Excelfore bring your legacy systems forward into the age of the Software Defined Vehicle, integrating seamlessly into an Ethernet backbone to provide full cloud accessibility to your CAN based devices.
Grand Synchronization
AVB networks provide a grand master clock to enable network traffic and connected devices to precisely synchronize across the network
➤ Generalized precision time protocol (gPTP): IEEE 802.1AS-2020
Traffic Shaping, Stream Prioritization, Bandwidth Reservation, AV Sync
Key AVB protocols shape the network traffic to give priority to mission-critical data & build redundancy into networks in safety-critical domains:
➤ Transport Protocol: IEEE1722 (AVTP)
➤ Credit-based shaper: IEEE 802.1Qav / 802.1Qat
➤ AVDECC Support: IEEE1722.1
➤ Application specific configurations: 802.1BA
Full RTP and RTCP support
➤ IEEE 1733-2011 RTCP AVB support
➤ Scalable design for multi-channel support
➤ Supports symmetric RTP/RTCP rfc4961
➤ Supports RTCP Reports: Sender and Receiver Reports, SDES, BYE, APP, AVB (IEEE Std 1733-2011)
➤ Developed and tested with Linux kernel though can be easily ported to other environment
➤ Classic AutoSAR compliant version also available
Library Size & Memory Usage
➤ ROM Code : 51.9 KB
➤ ROM Data : 276 B
➤ RAM Data : 812 B
Measured from xl4rtp library v1.0.0 build for Linux environment. Value may slightly vary depending on library version and intended build environment target.
➤ Peak Heap (RX) : 3832 B
➤ Peak Heap (TX) : 3064 B
Faster Time to Market
At Excelfore, we provide standards-based solutions with powerful tools to drive faster in-vehicle and cloud integrations.
Through Leaders in Automotive Connectivity
From the first AVNU-certified AVB protocol stacks, to the first implementation of a full eSync OTA stack, Excelfore leads the way in connected technologies.
Driving Standards and Interoperability
Excelfore actively drives standards and interoperability for in-vehicle networking and cloud connectivity.
Building Trust Through Partnership
Seamless integration is crucial to successful adoption of any technology. As your trusted partner, we provide comprehensive support throughout the integration process.
